RAM® Tab-Tite™ Holder for 9"-10.5" Tablets with Heavy Duty Cases | RAM-HOL-TAB20U

The RAM^® Tab-Tite^™ spring-loaded, quick release holder offers a secure fit with easy access to the mounted tablet. The spring-loaded design makes it easy to insert and remove your tablet, while keeping it secure in a variety of applications. The custom end cups are designed to optimize the functionality of your tablet, enabling access to all buttons, ports, and tablet functions. Included is a set of four nuts and bolts to attach the holder to any RAM^® components that contain the universal AMPS hole pattern. For off road environments and use in open cockpit applications, we recommended the use of a tether to assist in securing your device. The RAM^® Tab-Tite^™ holder is compatible with any tablet within the listed dimensions.

FEATURES

• Spring-loaded holder secures most 9" tablets with heavy-duty cases; interchangeable end cups allow you to modify the holder when upgrading devices
• Compatible with B and C size RAM^® round ball bases for attaching a double socket arm; ball and socket technology allows for near-infinite adjustability
• Made of high-strength composites for durability and reliability in the most demanding environments
• Backed by a lifetime warranty

HARDWARE INCLUDED

Assembly Hardware
(4) #8-32 x 5/8" Machine Screws
(4) #8-32 x 1/2" Machine Screws
(4) #8-32 Nylock Nuts

HOLDER DIMENSIONS

Height Range: 9.5" - 12.125"
Width Range: 6.55" - 7.43"
Depth Range: .3" - .875"

HOLE PATTERN

4-Hole AMPS: 1.181" x 1.496"

MATERIALS

High strength composite

PACKAGING TYPE

Poly Bag

WEIGHT

0.64 lb

INSTRUCTIONS

RAM^® Tab-Tite^™ Assembly Guide

DOCUMENTS

How to Find the Right Holder for Your Tablet

Off Road Catalog

On Road Catalog

Samsung Mounting Solutions Catalog

Apple Mounting Solutions Catalog
